Body Material: ABS
Size: 102*102*22mm+50mm (4.02″*4.02″*0.87″+1.97″)
Filling: Epoxy+Quartz sand
Lens Material: PMMA
Reflective Solar Cat Eyes Marker Features:
•Reflective Solar Cat Eyes studs water, oil, chemical, and heat resistance.
•Aluminium reflective Solar Cat Eyes road marker can work more than 3 years normally.
•Very high reflectivity.
•Reflective Solar Cat Eyes road studs easy installation with glues.
•Photometric values:exceeds 600(mcd/lux).
Reflective Solar Cat Eyes Road Stud Marker Parameters:
| Body material: | ABS |
| Filling: | Epoxy+Quartz Sand |
| Lens Material: | PMMA |
| Reflector type: | Double side/Single side |
| Quality: | ASTM D4280 & EN1463-1 standard |
| Size: | 102*102*22mm+50mm (4.02″*4.02″*0.87″+1.97″) |
| Packing: | 38*36*22.5cm, 50pcs/ctn (14.96″*14.17″*8.86″, 50pcs/ctn) |
| Weight: | 320g/pc; 19kg/ctn (0.71bs/pc; 41.89bs/ctn) |
Installation Method Of Reflective Solar Cat Eyes Road Stud Marker:
1. Determine the installation location and distance, clean the road surface, and ensure that the Solar Cat Eyes road studs are installed on a flat road surface.
2. Clean the bottom of the Solar Cat Eyes road studs and apply the epoxy glue evenly to the back of the studs.
3. Press the side with the glue on the road, fix the position, wait for the glue to dry.
4. Check within 2 hours of installation to ensure that all Solar Cat Eyes road studs are not installed incorrectly and are not bent or deformed due to compression.
5. Remove the installation isolation facility within 6-8 hours after the installation of the Solar Cat Eyes road studs.
